Electric Flap Barrier Gate With IR Sensor / Access Control Card Swipe Flap Turnstile

বেসিক ইনফরমেশন
Place of Origin: China
পরিচিতিমুলক নাম: WEJOIN
সাক্ষ্যদান: ISO
Model Number: WJTY201
Minimum Order Quantity: 2pcs
মূল্য: Negotiation
Packaging Details: Wooden box
Delivery Time: 5-15 days
Payment Terms: T/T, , Western Union
Supply Ability: 200PCS/week
বিস্তারিত তথ্য
Cabinet Material: 304 stainles Steel Wing Type: Arylic
Lane Wideth: 600mm Wing Wideth: 300mm
Package: Wooden Transit Speed: 30~40/min

পণ্যের বর্ণনা


Access control card swipe flap turnstile / electric flap barrier with IR sensor


Product Description:
  • Flap turnstile is designed to control pedestrians entering or exiting restricted areas, usually used of high pedestrian traffic flow in both directions.
  • The body is made from brushed stainless steel which creates a seamless and elegant access point to blend into most indoor environment.
  • It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint and Biometric device).
  • In case of emergency, the Optical Turnstile arm will open automatically to allow free passage.
  • Optical Turnstiles are suit for elegant and luxury entrance solutions.


Functions & Features:


1. Self-checking function.
2. Working types:
2.1,bi-direction card reading; direction card reading and another prohibited;
3. Automatic turnstiles arm drop automatically when power off ;Arm recover its position automatically when power on.
4. Arm open&close time can be set by user in control boards
5. Manager can set pass time in control boards.
6. Flap barrier automatic alarm when illegal pass until passenger get an authorized card.
7. Human safe: optical & mechanical anti-impact.Optical sensor detect passenger position.100% avoid passenger hurt during in passing . If arm meets any obstacle, arm stop working immediately .
8. LED display passengers numbers.
9. Direction display guide passenger go or stop.
10. Control software regulate authorized passengers numbers.
11. Stable running with low- noise.


Products Series:


Material of Housing 304 Stainless Steel
Material of Flap Door Organic Glass, Resin, or PVC
Dimension of housing 1200*270*1000 1450*315*1020 1400*305*1020
Thickness of housing 1.5mm
Max Width of Passage 600 900 900
Net weight 70kg 140 kg 85 kg
Normal Life Span 3 millions times
Communication Interface Standard RS485(distance less than 1200 meters)
Transit speed 30-40 persons/min
Power supply 220V±10%, 110± 10%
Frequency 50/60HZ
Working voltage of motor DC24V
Time for opening or closing 1s
Starting time after power on 3s
Input interface Dry contact signal or +12Vor pulse signal with width more than
100ms DC12V
Transit speed 25~32 persons/min
Working temperature -10°C~50°C
Working environment Indoor / Outdoor (Shelter)
Relative humidity ≤95%, no condensation
